ZERO EMISSIONS

The all-new Z e-1 ABS EV motorcycle produces a clean and comfortable ride through the city with zero emissions. Along with generating zero emissions, the compact fully electric motor delivers an enjoyable riding experience with quiet operation. Maintenance has never been easier as this all-new EV bike requires zero oil changes.

FRIENDLY POWER

The Z e-1 ABS is a full-size EV motorcycle powered by a quiet, compact brushless electric motor offering excellent response and torque for around-town riding. Riders can confidently control power output with clutch-less operation that contributes to a rider-friendly package.

RIDING MODES

The all-new Z e-1 ABS EV motorcycle is powered by dual removable battery packs. When both battery packs are charged and in use, the power system can be set to ROAD or ECO mode. ROAD mode produces full power capability and potential to reach max top speed. ECO mode reduces max power and max top speed. If only one battery pack is in use, then performance level defaults to ECO mode.

SPORTBIKE CHASSIS

The all-new Z e-1 ABS EV motorcycle features a lightweight frame with carefully tuned rigidity balance, coupled with sportbike suspension components. The result is light, predictable handling, and a rider-friendly riding experience. Front and rear disc brakes provide sure stopping performance, while ABS adds a measure of reassurance.

EASY RECHARGE

Thanks to the regenerative system, the energy of deceleration is recycled back to the battery, contributing to a longer cruising range. Riders have three options when it comes time to charge the two battery packs. The battery packs can be removed to be charged away from the motorcycle, either by direct charge or by a charging dock in a different location, or you can plug the charger directly into the motorcycle in a dry environment via the offboard charging adapter.

The offboard charging adapter is pre-installed on the motorcycle as standard equipment. One charger is included with the motorcycle and can be plugged into a standard 120V household outlet.

Specification:

POWER

• Motor Type - Air-cooled, interior permanent magnet synchronous motor
• Power Modes - 2 Modes (ROAD/ECO) plus e-boost
• Max Speed by Mode - ROAD = 53 mph (63 mph with e-boost), ECO = 40 mph (45 mph with e-boost)
• Rated Power - 5.0 kW (6.8 PS) / 2,800 min-1
• Maximum Power - 9.0 kW (12 PS) / 2,600-4,000 min-1
• Maximum Torque - 29.7 lb-ft @ 500 rpm
• Battery Type - Lithium-ion battery pack (x2)
• Battery Voltage/Capacity - 50.4 V 30 Ah (x2)
• Battery Range - 41 mi (approximate in ROAD Mode w/o e-boost)
• Battery Charge Time - 3.7 hours (x2)
• Transmission Type - Single reduction gear
• Shifter Mechanism - Push button
• Primary Reduction Ratio - 3.211 (61/19)
• Final Reduction Ratio - 3.867 (58/15)
• Final Drive Type - Chain
• Electronic Rider Aids - WALK Mode (with Reverse), Anti-lock Brake System (ABS)
